Categories | Static Transfer Switch STS |
---|---|
Place of Origin: | Guangdong, China |
Brand Name: | EATON |
Model Number: | EATS16N, STS-10/32A |
Number of Pole: | 3 |
Rated Current: | 16A |
Frame current: | 1 |
Max. Current: | 32A |
IP level: | IP11 |
Color: | White |
Product name: | STS AC220V sts single-phase STS static transfer switch |
Type: | High Voltage |
Material: | Copper |
Rated current: | 10A 16A 32A |
Rated voltage: | AC 220V |
Application: | Industrial |
MOQ: | 5 pieces |
Price: | $400.00/pieces >=5 pieces |
Company Info. |
Visench Technology Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
TECHNICAL SPECIFICATIONS | ATS 16 | ATS 16 Netpack | ATS 30 | |||
Nominal current | 16A | 16A | 30A* | |||
Input/output | ||||||
Nominal voltage/input frequency | 208/220/230/240 V ; 50/60Hz | |||||
Performance | ||||||
Typical transfer time | 8 ms | |||||
Safety | IEC/EN 62310-1,IEC/EN 60950-1 | IEC/EN 62310-1,IEC/EN 60950-1 | IEC/EN 60950-1 | |||
EMC | IEC/EN 62310-2 | |||||
Marking | CE | |||||
Connection | ||||||
Inputs | 2IEC C20 + 2 input cables | Hardwired | ||||
Outputs | 8 IEC C13 + 1 IEC C19 | Hardwired | ||||
Communication and user interface | ||||||
User interface | LCD | LED | ||||
Network communication | No | Yes | ||||
Dimensions and weight | ||||||
Dimensions H x W x D | 43 x 430 x 250mm | 43 x 430 x 250mm | 43 x 440 x 390mm | |||
Weight | 3,3 kg | 3,5 kg | 5 kg | |||
Customer Service & Support | ||||||
1 years guarantee | Standard exchange of the product | |||||
* 30A up to 35°C, 25.6A up to 40°C. | ||||||
Part Numbers | ATS 16 | ATS 16 Netpack | ATS 30 | |||
ATS | EATS16 | EATS16N | EATS30N | |||
Set of two 16 A connecting cables IEC | 66 397 | |||||
female connector / USE-DIN male connector | ||||||
length 1.5 m | ||||||
1 cable / IEC 10 A male to IEC 16 A female | 66 029 |
![]() |
