Wholesale high quality chicken wire mesh An additional coating hexagonal wire mesh

Categories Hot Galvanized Hexagonal Wire Mesh
Brand Name: ERIC
Model Number: ER847-1
Certification: ISO9000
Place of Origin: CHINA
MOQ: 10rolls
Price: 10usd per rolls
Payment Terms: L/C, T/T
Supply Ability: 100000rolls per month
Delivery Time: 10days
Packaging Details: waterproof paper with plastic film and or wooden pallect
galvanized: 30g-360g per suqre meter
mesh size: 5/8" 3/4" 1" 1-12"
wire diameter: 0.4-2.5mm
length: 15m-30m
types: weaving and hot zinc galvanized
tensile: 450-550N/mm2
width: 0.5m-3m
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Wholesale high quality chicken wire mesh An additional coating hexagonal wire mesh

Hexagonal wire netting is used for feeding chicken, ducks, gooses, rabbits and the fence of zoo, etc

Materials: Low carbon steel wire, stainless steel wire or brass wire
Weaving pattern: Straight twist, reverse twist, double-direction twist.
Processing: Twisted before galvanized, weaving after galvanized. Electro galvanized, hot dipped, plastic-coated, stainless steel, PVC coated, etc.
Galvanized hexagonal iron wire netting factory
Application: Hexagonal wire netting is used for feeding chicken, ducks, gooses, rabbits and the fence of zoo. Also used in machinery protection, fences for road, railway, etc. It can be made into box to hold stones and sand to protect the bank, hillside, bridge and other related civil engineering against the flood.

Galvanized hex. wire netting in normal twist (In 30M roll, width of 0.5M---2.0M)
MeshWire Gauge (BWG)
Inchmm
3/8"10mm27,26,25,24,23,22,21
1/2"13mm25,24,23,22,21,20
5/8"16mm27,26,25,24,23,22
3/4"20mm25,24,23,22,21,20,19
1"25mm25,24,23,22,21,20,19,18
1-1/4"32mm22,21,20,19,18
1-1/2"40mm22,21,20,19,18,17
2"50mm22,21,20,19,18,17,16,15,14
3"75mm21,20,19,18,17,16,15,14
4"100mm17,16,15,14

Our Services

1. After placing orders will be timely feedback to track the progress of related wire mesh production, shipment, delivery and other production conditions.

2. The third-party inspection always gets real and true data from us and we will send hot hexagonal wire mesh photos to client if there is no inspection from the third-party.

3. In accordance with the stipulated time of shipment delivery, guaranteed wire mesh delivery time and supply capacity.

4. Encounter any quality problems can always contact us, we will promptly communicate timely replacement of the goods .

5. Installation, maintenance and repair instructions with full information.

6. 3-10 years warranty depends on different products and using environment.

Specifications List of Pvc Coated Hexagonal Wire Mesh
OpeningWire Diameter
InchmmWire gauge (BWG)mm
1/4" x 1/4"6.4 x 6.422, 23, 240.7, 0.6, 0.55
3/8" x 3/8"10.6 x 10.619, 20, 21, 221, 0.9, 0.8, 0.7
1/2" x 1/2"12.7 x 12.716, 17, 18, 19, 20, 21, 22, 231.6, 1.5, 1.25, 1, 0.9, 0.8, 0.7, 0.6
5/8" x 5/8"16 x 1618, 19, 20, 21,1.25, 1, 0.9, 0.8
3/4" x 3/4"19.1 x 19.116, 17, 18, 19, 20, 211.6, 1.5, 1.25, 1, 0.9, 0.8
1" x 1/2"25.4 x 12.716, 17, 18, 19, 20, 211.6, 1.5, 1.25, 1, 0.9, 0.8
1-1/2" x 1-1/2"38 x 3814, 15, 16, 17, 18, 192.1, 1.8, 1.6, 1.5, 1.25, 1
1" x 2"25.4 x 50.814, 15, 162.1, 1.8, 1.6
2" x 2"50.8 x 50.812, 13, 14, 15, 162.8, 2.4, 2.1, 1.8, 1.6
4" x 4"101.6 x 101.612, 13, 14, 15, 162.8, 2.4, 2.1, 1.8, 1.6

galvanized hexagonal mesh sizeMin. Gal.v.WidthWire Gauge (Diameter)
InchmmTolerance(mm)G/SQ.MBWG
3/8"10mm±1.00.7mm - 1452' - 1MBWG23-27
1/2"13mm±1.50.7mm - 952' - 2MBWG21-25
5/8"16mm±2.00.7mm - 702' - 2MBWG22-27
3/4"20mm±3.00.7mm - 552' - 2MBWG19-25
1"25mm±3.00.9mm - 551' - 2MBWG18-25
1-1/4"31mm±4.00.9mm - 401' - 2MBWG18-23
1-1/2"40mm±5.01.0mm - 451' - 2MBWG18-23
2"50mm±6.01.2mm - 401' - 2MBWG18-23
2-1/2"65mm±7.01.0mm - 301' - 2MBWG18-21
3"±8.01.4mm - 302' - 2MBWG17-20
4"100mm±8.01.6mm - 302' - 2MBWG16-19

Hexagonal Wire Mesh Specification:

1. Material: Low Carbon Steel Wire,Stainless Steel Wire Mesh

2. Diameter: 0.1-4mm

3. Mesh Size: 3/8"-4"

4. Roll Width: 0.5m-2m

5. Surface Treatment: Galvanized or PVC Coated Hexagonal wire mesh

6. Weaving Types: Positive Twist, Negative Twist, Positive and Negative twist.

7. Feature: Firm structure,flat surface,anti-corrosion,anti-oxidation

8. Classifiction: Electro Galvanized before/after Weaving
Hot Dipped Galvanized before/after Weaving hexagonal wire netting
PVC Coated Before/After Weaving
Stainless Steel Hexagonal Wire Mesh
