| Categories | Low Pressure PU Foaming Machine |
|---|---|
| Brand Name: | Yongjia |
| Model Number: | Low Pressure Foam Machine |
| Certification: | CE |
| Place of Origin: | Jiangsu, China |
| MOQ: | 1 Set/Sets |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, |
| Supply Ability: | 50 Set/Sets per Month PU polyurethane low pressure foam mixing molding machine |
| Delivery Time: | 45-60 days |
| Packaging Details: | sea worthy wooden box for PU Polyurethane Low Pressure Foam Mixing Molding Machine for Sheet Foam |
| Product Name: | pu injection moulding machine |
| Injection Output: | 54-216g/s |
| Foam application: | All shaped memory foam pillows |
| Input power: | three-phrase five-wire，380V 50HZ |
| Rated power: | about 11KW |
| Raw Material: | Flexible Foam Polyol+Isocyanate |
| Company Info. |
| Yongjia Polyurethane Co., Ltd. |
| View Contact Details |
| Product List |
SPUF2A25-20 type low pressure foaming machine is newly developed by Yongjia company based on learning and absorbing advanced techniques abroad, which is widely employed in the production of automotive parts, automotive interior, toys, memory pillow and other kinds of flexible foams like integral skin, high resilience and slow rebound , etc. This machine has high repeat injection precision, even mixing, stable performance, easy operation, and high production efficiency, etc.
| No. | Item | Technical Parameter |
| 1 | Foam application | Flexible foam pillows |
| 2 | raw material viscosity(22℃) | ～3000CPS ～1000MPas |
| 3 | Injection Output | 54-216g/s |
| 4 | Mixing ratio range | 100:28～48 |
| 5 | Mixing head | 2800-5000rpm, forced dynamic mixing |
| 6 | Tank Volume | 120L |
| 7 | Metering pump | A pump: GPA3-25 Type B Pump: JR20 Type |
| 8 | Compressed air requirement | dry, oil free P:0.6-0.8MPa Q:600NL/min(Customer-owned) |
| 9 | Nitrogen requirement | P:0.05MPa Q:600NL/min(Customer-owned) |
| 10 | Temperature control system | heat:2x3.2kW |
| 11 | Input power | three-phrase five-wire,380V 50HZ |
| 12 | Rated power | about 11KW |
| 13 | swing arm | Rotatable swing arm, 2.3m(length customizable) |
Features of pu injection machine:
1. For sandwich type material bucket, it has good heat preservation
2. The adoption of PLC touch screen human-computer interface control panel makes the machine easy to use and the operating situation was absolutely clear.
3. Head connected with the operation system, easy for operation
4. The adoption of new type mixing head makes the mixing even, with the characteristic of low noise, sturdy and durable.
5. Boom swing length according to the requirement, multi-angle
rotation, easy and fast
6. High precision pump lead to measuring accurately
7. Easy for maintenance, operation and repair.
8. Low energy consumption.
Applications:
Also known as viscoelastic foam, memory foam contours in response to heat and pressure. The material provides a supportive, pressure-relieving cradle that makes it ideal for use in pillows.
Whether you suffer from neck pain or whether you’re simply looking for a pillow that will support your spine and help you get a better night’s sleep, look no further. Polyurethane foam pillow can meet all your requirements.
|
