| Categories | Rotary Slitter Blades |
|---|---|
| Brand Name: | SENDA |
| Model Number: | SD004 |
| Certification: | ISO9001 |
| Place of Origin: | China |
| MOQ: | 2pcs |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Delivery Time: | 30-35days |
| Packaging Details: | anti-rust oil in plastic bag and Packed in strong plywood case |
| Name: | coil slitting knives |
| Other name: | coil slitter blade |
| Material: | LD, SKD11,D2, M2, HSS, TCT etc |
| Thickness tolerance: | +-0.001mm |
| Inner Diameter: | +0.02mm |
| Flatness: | ≤0.002mm |
| Parallelism: | ≤0.002mm |
| Concentricity: | ≤0.02mm |
| Surface roundness: | Ra0.1um |
| Hardness: | 53~55HRC |
| Application: | metal coil processing factory |
| Company Info. |
| Senda Group Co.，Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
metal processing machine coil slitting knives for steel coils
Senda Rotary slitting knives for metal coil processing are mainly applied to slitter machine. Slitting blades cut for cold milling coil and hot milling coil etc. used in coil service center. SENDA offer slitter knives of Diameter max1500mm in various material options such as H13, H13K , SKD11, LD , D2 and so on. Our knives are offered in hardness range of 52-64 HRC with Thickness tolerances of up to +/- 0.001mm. We offer flatness within - 0.002mm and Parallelism tolerances within 0.002mm.
| Brand | Senda |
| Country of Origin | China |
| Material | D2, M2, HSS, TCT etc |
| Size: | Max. Cutting Size : outside diamete r: ￠800, thickness : 60mm |
| Thickness tolerance | +- 0.001mm |
| Inner Diameter | +0.02mm |
| Flatness | ≤0.002mm |
| Parallelism | ≤0.002mm |
| Concentricity | ≤0.02mm |
| Surface roundness | Ra 0.1um |
| Hardness | HRC53~55 |
| Packaging | wooden box with anti-rust film inside |
| Application | metal coil processing factory |
You may also need below items:
Rotary blades
Rubber rings
Metal distance rings
Straight Blades
Scrap Chopping Knives
Side Trimmer Blade
Plastic spacers
Separator Discs
Clamping nuts with grease
Senda starting from 1998, focus on the quality of products and provide better service. Now we have over 100 workers, CNC lathes, High precision internal and external circular grinding machines, heat-treatment furnaces grinding machines and inspection machines.
|
