| Categories | RF Shielding Copper Foil |
|---|---|
| Brand Name: | HAOZHUO |
| Model Number: | CF SERIES |
| Certification: | CE RoHS |
| Place of Origin: | P.R.CHINA |
| MOQ: | 100 KG PER ORDER |
| Price: | USD 15 PER KG |
| Supply Ability: | 10000 KG PER WEEK |
| Packaging Details: | CARTON |
| product: | COPPER FOIL/COPPER TAPE/COPPER WOOL |
| Alloy Or Not:: | Non-alloy |
| Thickness:: | 0.105mm,0.14mm, 0.105mm/0.14mm, 3oz/4oz |
| Width:: | 1370MM |
| application: | rf shielding room |
| MATERIAL: | 99.8% COPPER |
| customized: | not accepted |
| weight: | 1000Kg per roll |
| color: | true color |
| surface treatment: | not have |
| Company Info. |
| Changzhou Haozhuo Electronic Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
100% COPPER FOIL FOR MRI RF SHIELDING ROOM MEDICAL RF SHIELDING HIGH QULITY
EMI RFI shielding copper tape strip, lightning copper tape
Product description:
1. The product structure is based on copper foil as the substrate, conductive acrylic adhesive as the adhesive, plus release paper.
2. Three-tier architecture is very suitable for cutter mold or the metal mold die-cutting, Can be flat cutter or round cutter to die-cutting.
3. The width of the product available from 3mm ~ 380mm. Standard length is 50m., also do 100m, 150m or longer, save customers the trouble of frequently reloading.
| Product description | |
| Name | copper foil |
| Material | 99.8% copper |
| Width | standard 1350mm |
| Thickness | standard 0.105mm(3oz),0.14mm(4oz) |
| Feature | EMI shielding |
| Application | faraday cage,MRI room |
| Part Number | Backing Material | Thickness of Backing (mm) | Total Thickness (mm) | Holding Power Min/inch | Adhesion Strength kg/25mm | Adhesive Component | Shield Efficacy 10MHz~ 1GHz (dB) | Conductivity z-ohms | Integrated thermal conductivity (W/mK) |
| XPH0M123 | Copper Foil | 0.012 | 0.030±0.01 | ≥1440 | >0.8 | Acrylic | ≥60 | <0.03 | 60 |
| XPH0M183 | Copper Foil | 0.018 | 0.050±0.005 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 60 |
| XPH0M253 | Copper Foil | 0.025 | 0.06±0.005 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 80 |
| XPH0M353 | Copper Foil | 0.035 | 0.070±0.005 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 90 |
| XPH0M503 | Copper Foil | 0.050 | 0.085±0.005 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 110 |
| XPH0M753 | Copper Foil | 0.075 | 0.11±0.01 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 130 |
| XPH0MA03 | Copper Foil | 0.100 | 0.135±0.01 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 160 |
| XPH0MA23 | Copper Foil | 0.125 | 0.15±0.015 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 170 |
| XPH0MA53 | Copper Foil | 0.150 | 0.20±0.02 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 190 |
|
