HDMI 21.5 Inch 5C Series Open Frame Touch Monitor , Portable Touch Monitor

Categories Open Frame Touch Monitor
Brand Name: GreenTouch
Certification: CE, FCC, ROHS
Place of Origin: China
MOQ: 1
Payment Terms: T/T, MoneyGram
Supply Ability: 10,000pcs per month
Delivery Time: 10 working days after received your payment
Packaging Details: Packed in carton firstly,and then reinforced with wooden case for outer packing
Model Number: GT-TM-2155C
Interface Type: DVI,VGA,HDMI
Touch life: More than 5,000million times
Resolution: 1280x1024
Scan Frequency(L/F): Horizontal:30~80KHz ,Vertical: 55~75Hz
Mean Time Between Failure (MTBF): 30,000 hours
Environment: Operating humidity:20% to 80% Storage humidity:10% to 90%
Ratio: 16:9
Brightness(Typ.): 250cd/m²
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

HDMI 21.5 Inch 5C Series Open Frame Touch Monitor , Portable Touch Monitor

Touch Interface 21.5 Inch Touch Screen Monitor Outstanding Vivid Color Image Quality
Description:

  1. Long lasting product cycle-enclosure controlled by GreenTouch specifications
  2. High quality panel with high brightness,high contrast ratio and broad viewing angle
  3. Multiple mounting options including VESA mount, horizontal or vertical bracket-mount
  4. Superior viewing angles, contrast ratio and brightness
  5. Our products have passed CE, FCC, RoHS certification!

Product Specification:

Part Number

Standard Type:GT-TM-2155C
HDMI Type:GT-TM-2155C-CTW-HD

Enclosure/Bezel ColorBlack front cover,Silver back cover
LCD TypeActiver matrix TFT LCD,LED backlight
Diagonal21.5"diagonal
Ratio16:9
Active Area DimensionsHorizontal:476.6mm;Vertical:268.1mm
Monitor SizeWidth:553.0mm x Height:346.0mm x Thickness:47mm
Resolution1280x1024@60Hz
Other available Resolution1024x768;800x600;720x400;720x350;640x480;60Hz;65Hz75Hz
Color16.7M
Brightness(Typ.)250cd/m²
Brightness(Standard)(cd/M2)5ms
Viewing Angle(from center)Horizonta(left/right):±89° or total 178°
Vertical(up/down):±89° or a total of 178°
Contrast ratio(Standard)1000:1
Input video formatsAnalog VGA and digital DVI(optional HDMI)
Input video Signal Connector

Female head DE-15 connector,female head DVI-D,Dual-Link connector,
female head HDMI connector

Scan frequencyHorizontal:31.5-60.2kHz;vertical:56.3-75Hz
Power

External DC,input voltage DC:12V;INPUT POWER CONNECTOR SPECIFICATIONS(for all in one PC)
-Type:DC cartridge receptacle;Cartridge ID:5.5mm(±0.3mm);Needle OD:2.0mm
(+0.0-0.1mm);Cartridgedepth:8.0mm(±0.3mm)

Power connector(on power adapter)-Type:DC cartridge Plug:Cartridge
OD:5.5mm(±0.1mm);Needle Inner Diameter:2.1mm(±0.1mm);Cartridge
Length:9.5mm(±0.5mm)

Power consumption(Standard)Display only:13.0W(Typ.)
TemperatureOperating:0℃to40℃;Storage:-20 ℃ to 60 ℃
Humidity

Operating:20% to 80% (no condensation);Storage:10% to 90%
(non-condensing)

MTBF50000 hours
Weight(approx.)Net weight:4.3kg(Typ.);Shipping:5.8kg
Warranty1 year
OSDDigital OSD
User Controls

OSD Button:Menu,UP,Down,Select,Power;OSD:Contrast,Brightness,
Horizontal/Vertical Bits Clock,phase,call default,language(English,
German,Spanish,Japanese,French);OSD Fail/Active:Power,OSD menu

Mounting options100mm or 75mm VESA mounting,open bracket mounting
Agency ApprovalsUUL,cUL(Recognized),FCC,CE,China RoHS CQC

Application
Suitable for hotel reception,industrial manufacturing, kiosks, ATM,Hospital , offices, information systems ,

Education, pharmacy,department store and other interactive touch application design .


Industrial touch monitor Advantages

GreenTouch's Industrial touch monitor use 4mm/6mm Vandal proof SAW Touch screen that independently developed and produced by our company. It has a high-quality, cost-effective, good durability, and stability character.Higher sensitivity and response speed than same product, very smoothly when touch and draw line.
Product overview

GreenTouch's Industrial touch screen monitor size from 15 to 19 inches, use with 4mm/6mm Vandal proof SAW Touchscreens that independently developed and produced by our company.
It has a high-quality, cost-effective, good durability, and stability character.Higher sensitivity and response speed than same product.Removeable External mounting bracket and National standard VESA install holes.National standard professional production line, one million dust-free environment ,screen body and LCD screen fit.This kind of the open frame constructure and Removable side mounting bracket are very good for Kiosk ,touch terminal etc.
