Recessed Mounted 24GHz Lifesnor Sensor Built In Tuya ZigBee Wireless Module MSA201 Z

Categories Presence Detectors Sensor
Brand Name: Merrytek
Model Number: MSA201 Z
Certification: CE
Place of Origin: China
MOQ: 50PCS
Payment Terms: T/T
Delivery Time: 5 to 8 working days
Packaging Details: Giftbox
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Recessed Mounted 24GHz Lifesnor Sensor Built In Tuya ZigBee Wireless Module MSA201 Z

MSA201 Z is a 24GHz radar sensor based on Merrtek patented orthogonal half-wave bending antenna. Its antenna has high gain and wide detection range and is combined with Merrytek’s unique software algorithm. It can accurately detect minor movements brought by human in almost all indoor spaces and provide fast and accurate front-end sensing input for presence detectors, smart hotel, smart office and other scenes.

Input/Output Voltage Range 220-240Vac 50Hz/60Hz
Rated Voltage 220V AC
Working Current 50mA max
Working Power ≤1W 230V AC
Communication Model Frequency 2.4GHz-2.484GHz ZigBee Transmitting Frequency: 10dB Receiving Sensitivity: -101±2dBm
Sensor Parameter Transmitting Working Frequency 24GHz-24.25GHz ISM Wave.
Transmitting Power 5mW Max.
Detection Area

0% 25% 50% 75% 100%

(set by APP or remote control MH10)

Hold Time

30s /1min / 2min/ 3min /5min /10min /20min/30min

(set by APP or remote control MH10)

Daylight

When the change in ambient illuminance meets the preset illuminance difference, the sensor immediately reports the ambient illuminance value

The change value: 10-100lux, set by APP

Illuminance 5-1200Lux

Detecting Range

(100% detection area, radius)

Movement: 4-5m (at 3m height)

Minor Movement: 4-5m (at 3m height)

Presence: 3-4m (at 3m height)

Mounting Height 2.5-4.0m typical value: 3m
3db Beam Angle 100° (XZ field)
100° (YZ field)
Environment Working Temperature 0℃...+50℃
Storage Temperature -25℃~+80℃
Certificate Standard Certificate FCC/RED
Environmental Requirement Compliant to RoHS
IP Rating IP20
Note: "N/A" means not available.
