240×320 Dot Matrix Lcd Module ISO9001 ST7789V Ips Tft Screen Module

240×320 Dot Matrix Lcd Display Module Ips ALL Viewing Direction Tft Screen Module

1.Product parameter

ITEM	STANDARD VALUES
LCD type	2.4"
Dot arrangement	240(RGB)×320 dots
Color filter array	RGB vertical stripe
Display mode	IPS/Transmissive/NormallyBlack
Viewing Direction	80/80/80/80
Driver IC	ST7789V
Module size	42.72(W)×60.26(H)×2.1(T) mm

2. Product Drawings

3.Product Description

ChengHao Display model CH240QV47A is a color active matrix thin film transistor (TFT) liquid crystal display

(LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel,

a driving IC, a back-light and FPC.
This TFT LCD has a 2.4 (Vertical screen) inch diagonally measured active display area with 240*3(RGB)*320

resolution.
The driver used for this project is the HX8238D or compatible and can display 65k/262k colors by R.G.B. signal

input. The driver is mounted on the glass and the interconnection via FPC including components to drive the

display module.
In addition, FPC can also be customized according to customer requirements, such as modifying back-light and

FPC structure, interface definition, etc.
RoHS Compliance & Halogen Free.

We can according to your demand to customized your display.

Such as customized the frame, backlight brightness, backlight shape, long-life led wick,

FPC shape and interface definition, silk-printing your Logo and so on.

Module Type	Display Area	Display Mode
1.44 inch	25.50 * 26.50 mm	Normally White IPS, Transmissive
1.44 inch	25.50 * 26.50 mm	Normally White TN, Transmissive
1.50 inch	29.76 * 22.32 mm	Normally Black IPS, Transmissive
1.54 inch	27.72 * 27.72 mm	Normally Black IPS, Transmissive
1.54 inch	27.74 * 27.74 mm	Normally Black IPS, Transmissive
1.77 inch	28.03 * 35.04 mm	Normally White TN, Transmissive
1.80 inch	28.03 * 35.04 mm	Normally White TN, Transmissive
2.00 inch	30.60 * 40.80 mm	Normally White TN, Transmissive
2.10 inch	Circular display area	Normally White IPS, Transmissive
2.31 inch	46.75 * 35.06 mm	Normally White TN, Transmissive
2.40 inch	36.72 * 48.96 mm	Normally White TN, Transmissive
2.40 inch	36.72 * 48.96 mm	Normally White IPS, Transmissive
2.80 inch	43.20 * 57.60 mm	Normally White TN, Transmissive
2.80 inch	43.20 * 57.60 mm	Normally White IPS, Transmissive
3.00 inch	36.72 * 65.28 mm	Normally Black IPS, Transmissive
3.20 inch	48.60 * 64.80 mm	Normally White TN, Transmissive
3.50 inch	70.08 * 52.56 mm	Normally White TN, Transmissive
3.50 inch	70.08 * 52.56 mm	Normally Black IPS, Transmissive
4.00 inch	51.84 * 86.4 mm	Normally Black IPS, Transmissive
4.00 inch	71.86 * 70.18 mm	Normally Black IPS, Transmissive
4.30 inch	95.04 * 53.86 mm	Normally White TN, Transmissive
4.30 inch	95.04 * 53.86 mm	Normally Black IPS, Transmissive
5.00 inch	110.88 * 62.83 mm	Normally White TN, Transmissive
5.00 inch	108.00 * 64.8 0mm	Normally Black IPS, Transmissive
5.50 inch	68.04 * 120.96 mm	Normally Black IPS, Transmissive
6.00 inch	74.52 * 132.48 mm	Normally Black IPS, Transmissive
7.00 inch	154.08 * 85.92 mm	Normally White TN, Transmissive
7.00 inch	153.6 * 90 mm	Normally White TN, Transmissive
7.00 inch	154.21 mm * 85.92 mm	Normally Black IPS, Transmissive
8.00 inch	107.64 * 172.22 mm	Normally Black IPS, Transmissive
9.00 inch	196.61 * 114.15 mm	Normally White TN, Transmissive
10.1 inch	135.36 * 216.58 mm	Normally Black IPS, Transmissive
