Condition: | New |
Type: | Filling Machine |
Machinery Capacity: | 13000BPH |
Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Restaurant, Home Use, Retail, Food Shop, Food & Beverage Shops |
Showroom Location: | None |
Application: | Food, Beverage, Commodity, Chemical, Cosmetic |
Packaging Type: | Bottles, case, kit |
Packaging Material: | Plastic |
Automatic Grade: | Automatic |
Driven Type: | Electric |
Voltage: | AC220V/380V 50/60Hz |
Place of Origin: | Guangdong, China |
Brand Name: | Guanhong |
Dimension(L*W*H): | 3200*2000*1518mm |
Weight: | 1800 KG |
Warranty: | 1 Year |
Key Selling Points: | Automatic |
Filling Material: | Water, Oil, liquid, Liquid |
Filling Accuracy: | ±0.5% |
Machinery Test Report: | Provided |
Video outgoing-inspection: | Provided |
Warranty of core components: | 1 Year |
Core Components: | Motor, PLC |
Quantity of filling head: | 24 heads |
Filling capacity: | 0.3-0.8ml |
Filling form: | peristaltic pump filling |
Filling speed: | about 180 bottles/min |
Pressure: | 0.6-0.8 MPa |
Program control: | PLC+touch screen |
Power supply: | AC220V/380V, 50/60Hz. |
Sealing and cutting method: | heat sealing (first cutting, and then heat sealing) |
Materia: | the frame adopts 304# stainless steel + aluminum alloy |
Marketing Type: | Hot Product 2019 |
Packaging Details: | wooden packing |
Port: | Guangzhou |
Supply Ability: | 20 Unit/Units per Month |
Price: | $78,000.00/sets 1-1 sets |
MOQ: | 1 set |
Company Info. |
Guangzhou Guanhong Machinery Equipment Co., Ltd. |
Verified Supplier |
View Contact Details |
Product List |
NO. | item | value |
1 | Filling speed | 180 bottles/minute |
2 | Bottle feeding method | vibration plate bottle feeding |
3 | Number of vibration bottle sorte | 4 (2 for each bottle) |
4 | Bottle putting method | mechanicalarm putting bottle |
5 | Number of die holes | 24 holes |
6 | Filling method | peristaltic pump filling |
7 | Filling capacity | about 0.3ml |
8 | Filling accuracy | ±5% |
9 | Number of sealingand cuttingheads | 24 |
10 | Sealing and cutting method | heat sealing (first cutting, and then heat sealing) |
11 | Pull film method | electric automatic pull film |
12 | Coding form | mobile coding (move once, coding 24 bottles) |
13 | Discharging method | cylinder feeding |
14 | Production speed | 180 bottles/min |
15 | Material | the frame adopts 304# stainless steel + aluminum alloy |
16 | The whole machine power | about 6KW |
17 | Program control | PLC+ touch screen |
18 | Air pressure | 0.6-0.8mpa |
19 | Power supply | AC220V/380V, 50/60Hz. |
20 | Machine size | 3200*2000*1518mm |
![]() |
