| Categories | Aluminum Conductor |
|---|---|
| Certification: | ISO, CCC, RoHS |
| Brand Name: | Qifan |
| Model Number: | Copper conducotr |
| Place of Origin: | China |
| MOQ: | 100m |
| Price: | usd3-8/meter |
| Payment Terms: | D/A, D/P, L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 50ton Per Day |
| Delivery Time: | 30-45days |
| Packaging Details: | wooden drumsPackaging Details Inner Packing: Wooden reel, Plastic reel, and Paper Reel Outer Packing: Carton box, Pull out box, Pallet available Other packing available according to clients' request |
| Model NO.: | Copper conducotr |
| Wire Core Material: | Bare Copper Wire |
| Model: | HD Copper Wire |
| Brand: | Qifan |
| Warranty: | 10 Years |
| QC: | 200 |
| Color: | Copper |
| Transport Package: | Reel and Drum |
| Specification: | 1/0 2/0 4/0 |
| Trademark: | qifan |
| Origin: | China |
| HS Code: | 761410000 |
| Application: | Overhead |
| Voltage: | Low and Medium Voltage Cable |
| Current: | DC & AC |
| Insulation Material: | Bare |
| Sheath Material: | Bare |
| Material Shape: | Round Wire |
| Company Info. |
| Fangyu(shanghai)Automation Technology Co.,Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Hdbc Bare Hard Drawn HD Copper Conductor
| Nominal Cross Sectional Area | Conductor construction | Approx. overall diameter | Approx. overall weight | Current Capacity | Minimum breaking load |
| mm² | No. x Ø ( mm ) | mm | Kg / km | A | KN |
| 10 | 7 x 1.35 | 4.1 | 90 | 90 | 4.02 |
| 16 | 7 x 1.70 | 5.1 | 143 | 125 | 6.38 |
| 25 | 7 x 2.10 | 6.3 | 218 | 160 | 9.72 |
| 35 | 7 x 2.50 | 7.5 | 310 | 200 | 13.77 |
| 50 | 7 x 3.00 | 9.0 | 446 | 250 | 19.84 |
| 50 | 19 x 1.80 | 9.0 | 437 | 250 | 19.38 |
| 70 | 19 x 2.10 | 10.5 | 596 | 310 | 26.38 |
| 95 | 19 x 2.50 | 12.5 | 845 | 380 | 37.39 |
| 120 | 19 x 2.80 | 14.0 | 1060 | 440 | 48.90 |
| 150 | 37 x 2.25 | 15.8 | 1337 | 510 | 58.98 |
| 185 | 37 x 2.50 | 17.5 | 1649 | 585 | 72.81 |
| 240 | 61 x 2.25 | 20.3 | 2209 | 700 | 97.23 |
| 300 | 61 x 2.50 | 22.5 | 2725 | 800 | 120.04 |
| 400 | 61 x 2.89 | 26.0 | 3640 | 960 | 160.42 |
| 500 | 61 x 3.23 | 29.1 | 4545 | 1110 | 200.38 |
Shanghai Qifan Cable Co., Ltd. founded in 1994, has been
specialized in R&D and manufacturing of electric wires and
cables for more than 20 years, and it has advanced production and
testing equipment.
Qifan Cable has ability in producing many varieties of cables, such as High Voltage cables, Medium Voltage cables, Low Voltage cables, Control cables, Instrument cables, Building wires, Rubber cables etc. Qifan Cable has sold its products to over 30 countries and regions in Asia, Europe, Oceania, America and Africa. As a result, they are widely used in such industries as water conservancy, electricity, metallurgy, petrochemical, railway, transportation, communication, construction, urban, infrastructure construction, etc.
Since its establishment, Qifan Cable has abided by the operation principle of quality foremost. It took the lead in passing ISO 9001:2000 quality system certification in 2006 and ISO 14001:2004 environmental management system certification.
Qifan Cable-Make pioneering efforts and forge ahead!
|
